SNOW BLOWERS/THROWERS SNOW THROWER 45-5082-669 42", 587293701, 2019-01
>
CONTROL PANEL & DISCHARGE CHUTE
Back to
SNOW BLOWERS/THROWERS
SNOW THROWER 45-5082-669 42", 587293701, 2019-01
CONTROL PANEL & DISCHARGE CHUTE
SNOW BLOWERS/THROWERS
SNOW THROWER 45-5082-669 42", 587293701, 2019-01
Hover mouse on parts list
Wheel:
Zoom, left button:
Movement
Other parts
For
SNOW THROWER 45-5082-669 42", 587293701, 2019-01
6
NUT
Nut, Hex Lock 1/2-13
501334101
7
PEN
Pin, Hair Cotter 5/64"
501347001
8
PEN
Pin, Cotter 1/8" x 3/4"
501341301
9
COTTER PIN
Pin, Cotter 1/8" x 1-1/2"
577776801
10
WASHER
Washer, 17/32" x 1"
501334501
11
BOLT
Carriage Bolt, 3/8-16 x 1"
501332301
16
ROD
Rod, Spacer
501341801
17
BOLT
Hex Bolt, 5/16-18 x 1" (Locking)
501341901
18
LOCKWASHER
Lock Washer, 5/16"
522758601
25
REFLECTOR
Reflector, Rear
501342601
27
BOLT
Bolt, Hex 5/16-18 x 3/4
522759901
28
BOLT
Hex Bolt 5/16-18 x 1"
531007426
30
HAIR PIN COTTER
Pin, Haircotter #4 (1/8")
522752001
31
PLATE
Plate, Side (R.H.)
501343001
32
PLATE
Plate, Side (L.H.)
501343101
33
RIVET
Rivet, Pop
522756101
34
NUT
Hex Nut, 3/8-16 Nylock
501332701
39
BRACKET
Bracket, Chute Crank
501337801
42
GRIP
Grip
522836001
43
NUT
Palnut, 3/8"
531002840
52
NUT
Nut, Hex Lock 5/16-18
531007616
53
WASHER
Washer, 5/16"
522770301
54
PLATE
Plate, Mounting (L.H.)
501344101
55
PLATE
Plate, Mounting (R.H.)
501344201
56
WASHER
Washer, 1.59" x 1.032" x .060"
501344301
57
BRACKET
Hanger Bracket Assembly, L.H.
501338101
58
BRACKET
Hanger Bracket Assembly, R.H.
501338201
59
BOLT
Bolt, Hex 5/16-18 x 3/4" Self Thd.
501336501
60
TIE WRAP
Tie, Nylon
501331401
62
NUT
Nut, Flanged Lock 3/8-16
501338901
63
NUT
Nut, Nylock Hex 5/16-18
501332601
64
WASHER
Washer, 1/2"
501332001
65
BOLT
Carriage Bolt, 5/16-18 x 1"
522770201
66
BOLT
Bolt, Shoulder
501339401
67
WASHER
Washer, Bowed
531002816
68
BOLT
Carriage Bolt, 5/16-18 x 1-1/4"
501344601
69
BOLT
Carriage Bolt, 5/16-18 x 1-3/4"
501344501
70
PEN
Pin, Pivot Lock
501338701
75
NUT
Nut, Hex 3/8-16
531004664
77
NUT
Nut, Jam Nylock 3/8-16
586805301
79
LOCKWASHER
Lock Washer, 3/8"
577157101
81
SCREW
Bolt, Hex 5/16-18 x 1-1/4"
531008117
84
WASHER
Washer, .343" x .687" x .0673"
501342701
