Spare parts > Castelgarden > Trimmer/Brushcutter > XB 250 J XB 250 J (2014) > Handle-transmission
Back to
Handle-transmission
XB 250 J XB 250 J (2014)
Hover mouse on parts list
Wheel: Zoom, left button: Movement
Other parts For XB 250 J (2014)
1 Clutch Drive 118802113/0
2 Flat washer 2312010
3 Screw 2135030
4 Transmission Support Case 118802080/0
5 Nut 112293202/0
6 Grower 112583500/0
7 Washer 112521350/0
8 Flywheel 118802073/0
9 Screw 2135050
11 Crank Case 118802078/0
12 Electronic Coil 118802072/0
13 Seal Ring 118801188/0
14 Bearing 119216035/0
15 Crankshaft 118802066/0
16 Flywheel Key 123072002/0
17 Crankcase Gasket 118802090/0
18 Crank Case 118802079/0
19 Starter Cup 118804858/0
20 Starter Assy Yellow 118802068/0
21 Starter Handle 118802156/0
22 Starter Pulley 118802157/0
23 Starter Spring 118802158/0
24 Grommet 118802087/0
25 Tank Protection 118802083/0
26 Screw 2132510
27 Needle Bearing 118802075/0
28 Circlip 118802084/0
29 Piston Pin 118802081/0
30 Piston 118802076/0
31 Piston Ring 118802077/0
32 Cylinder Gasket 118802091/0
33 Cylinder 118802074/0
34 Screw 2135060
35 Spark Plug 3210024
36 Black Cylinder Cover 118802085/0
37 Washer 112523020/0
38 Screw 2135040
39 Screw 123878020/0
40 Screw 2135250
41 Washer 2330020
42 Washer 2312020
43 Muffler Guard 118802082/0
44 Muffler 118802067/0
45 Muffler Gasket 118802093/0
46 Intake Manifold Gasket 118802092/0
47 Intake Manifold 118802086/0
48 Carburetor Gasket 118802089/0
49 Carburetor 118802071/0
50 Air Filter Assy Black 118801194/0
51 Deflector 118801525/0
52 Air Filter 118801526/0
53 Plate 118802110/0
54 Air Cleaner Cover, Black 118802111/0
55 Knob 118801528/0
56 Screw 2135260
57 Fuel Tank Assy 118802070/0
58 Fuel Pipe 118802096/0
59 Fuel Cap Assy 118802097/0
60 Grower 112581200/0
61 Washer 112523000/1
62 Screw 118805051/0
63 Washer 118804045/0
