Spare parts
Everything for your machines
Spare parts > Gardena > TRIMMERS/EDGERS > EDGING ACCU SHEAR ACCU 45 EDGING ACCU SHEAR ACCU 45, 8808, until 2007 > PRODUCT COMPLETE
Back to
PRODUCT COMPLETE
EDGING ACCU SHEAR ACCU 45 EDGING ACCU SHEAR ACCU 45, 8808, until 2007
Hover mouse on parts list
Wheel: Zoom, left button: Movement
Other parts For EDGING ACCU SHEAR ACCU 45, 8808, until 2007
3 SCREW 2500-00.600.48
2500-00.600.48 		520450101
8 NUT 2500-00.600.41
2500-00.600.41 		520449901
15 SHEET METAL SCREW 4.2X19 1182-00.600.02
2546-00.600.28 		520452401
16 PRESSURE SPRING 2179-00.600.65
2179-00.600.65 		520428401
18 MOTOR ASSY 2500-00.610.00
2500-00.610.00 		520450301
20 SCREW 2500-00.600.46
2500-00.600.46 		520450001
21 GEAR WHEEL 2500-00.600.32
2500-00.600.32 		520449701
22 STRIP
2320-00.000.29 		520432501
23 WRAP-SPRING CLUTCH - EXCENTER
8800-00.610.00 		520606901
26 WHEEL COVER 8804-00.600.26
8804-00.600.26 		520608401
27 LOCKWASHER 2165-00.600.27
2165-00.600.27 		520427501
30 MESSERSCHUTZ 2345-00.610.02
2345-00.610.02 		523832501
42 BATTERY CHARGER 8804-00.650.00
8804-00.650.00 		520608701
24,25 RUNNER / SKID 8804-00.720.00
8804-00.720.00 		520608901
26,27,28,29 WHEEL SET 8893-00.630.00
8893-00.630.00 		576768501
30,31,32,33,34 BLADE 2345-00.610.00
2345-00.610.00 		520433401
4,5 BATTERY COVER, CPL. 8804-00.800.46
8804-00.800.46 		520609201
