Spare parts > Gardena > WATERING > TURBO-DRIVE-SPRINKLER WITH SLED TURBO-DRIVE-SPRINKLER WITH SLED, 830, until 2008 > PRODUCT COMPLETE
Back to
PRODUCT COMPLETE
TURBO-DRIVE-SPRINKLER WITH SLED TURBO-DRIVE-SPRINKLER WITH SLED, 830, until 2008
Hover mouse on parts list
Wheel: Zoom, left button: Movement
Other parts For TURBO-DRIVE-SPRINKLER WITH SLED, 830, until 2008
1 NOZZLE 1548-00.600.26
1548-00.600.26 		520393401
3 O-RING 4,9X1,9 945-00.000.11
945-00.000.11 		520333401
8 CONNECTING WHEEL 1976-00.600.51
1976-00.600.51 		520424901
9 SIEVE 1579-00.600.11
1579-00.600.11 		520398601
10 MAIN AXLE. PRINTED 832-00.600.40
832-00.600.40 		520320101
11 WASHER 1976-00.600.68
1976-00.600.68 		520425001
12 SLIDE RING 991-00.600.31
991-00.600.31 		520337501
TAP CONNECTOR CPL. 3/4 901-00.100.00
901-00.100.00, not shown in image 		520331801
2,3 ADJUSTMENT WHEEL 832-00.702.00
832-00.702.00 		520320301
