Spare parts > Gardena > WATERING > HIGH PRESSURE CLEANER AQUACLEAN LI-40-60 HIGH PRESSURE CLEANER AQUACLEAN LI-40-60, 9341, > PRODUCT COMPLETE
Back to
PRODUCT COMPLETE
HIGH PRESSURE CLEANER AQUACLEAN LI-40-60 HIGH PRESSURE CLEANER AQUACLEAN LI-40-60, 9341,
Hover mouse on parts list
Wheel: Zoom, left button: Movement
Other parts For HIGH PRESSURE CLEANER AQUACLEAN LI-40-60, 9341,
1 SCREW
9341-00.600.25 		596753501
2 HANDLE
9341-00.600.24 		594981601
3 NET
9341-00.600.42 		594989701
6 CAP
9341-00.600.02 		596975701
8 TUBE
9341-00.600.17 		594969901
12 CLIP
9341-00.600.08 		594976401
13 HOLDER
9341-00.600.07 		594977301
14 CLIP
9341-00.600.06 		594977101
17 WASHER
9341-00.600.31 		596750601
18 WHEEL ASSY
9341-00.612.00 		597206001
19 WASHER
9341-00.600.32 		596750501
21 PUMP
9341-00.615.00 		594969601
22 TUBE
9341-00.600.39 		594979301
23 CLIP
9341-00.600.40 		597196901
24 WASHER
9341-00.600.29 		596972301
26 SEALING RING
9341-00.600.41 		596971901
27 NUT
9341-00.600.28 		596972201
28 INLET
9341-00.600.11 		594982401
29 TAP CONNECTOR 18201-00.600.00
18201-00.600.00 		586705901
30 VALVE
9341-00.622.00 		597093901
31 WASHER
9341-00.622.03 		594982201
32 CONTAINER
9341-00.621.00 		594981701
33 SEAL
9341-00.620.02 		596975201
34 CAP
9341-00.620.01 		594981801
38 CONTROL BOARD
9341-00.625.00 		594980301
43 HOUSING
9341-00.600.01 		594968201
44 SEALING
9341-00.600.16 		596750901
48 SPRING 9860-00.600.20
9860-00.600.20 		590332601
51 COVER
9341-00.600.05 		594970401
53 PRESSURE HOSE
9341-00.630.06 		597006201
56 PIN
9341-00.630.07 		597006501
57 NOZZLE
9341-00.630.02 		597006101
58 TUBE
9341-00.630.05 		597006401
59 HANDLE
9341-00.630.04 		597006301
60 BATTERY 9842-00.701.00
9842-00.701.00 		590072601
61 CHARGER 9845-00.701.00
9845-00.701.00 		590072801
62 MOTOR ASSY
9341-00.615.02 		594969501
63 WASHER
9341-00.615.13 		596747301
65 CONNECTOR
9341-00.615.04 		595006301
67 TUBE
9341-00.615.30 		596751001
68 SWITCH
9341-00.615.31 		597145701
69 CONNECTOR
9341-00.615.03 		595006101
70 SEALING RING
9341-00.615.21 		597147101
71 PIN
9341-00.615.20 		597144801
72 PLUG
9341-00.615.08 		597146001
73 SEALING RING
9341-00.615.22 		597147201
74 SEALING RING
9341-00.615.23 		597147401
75 WASHER
9341-00.615.24 		597129601
76 PRESSURE SPRING
9341-00.615.25 		597146501
77 WASHER
9341-00.615.26 		597129501
78 VALVE
9341-00.615.11 		597146401
79 SEALING RING
9341-00.615.27 		597147501
80 VALVE
9341-00.615.07 		597146101
81 SEALING RING
9341-00.615.28 		597147601
82 SCREW
9341-00.615.29 		597146201
83 PLUG
9341-00.615.10 		597143101
84 SEALING RING
9341-00.615.19 		597147001
85 COVER
9341-00.615.09 		597142201
86 SPRING
9341-00.615.18 		597146901
87 VALVE
9341-00.615.06 		597146301
88 SEALING RING
9341-00.615.17 		597146801
89 SEALING RING
9341-00.615.16 		597146701
90 SEALING RING
9341-00.615.15 		597146601
91 CHECK VALVE
9341-00.615.05 		597129201
54,55 NOZZLE
9341-00.630.03 		595006401
