Spare parts > Husqvarna > TRACTORS/RIDE MOWERS > YTH20K46 YTH20K46, 96043027700, 2017-11 > ENGINE
Back to
ENGINE
YTH20K46 YTH20K46, 96043027700, 2017-11
Hover mouse on parts list
Wheel: Zoom, left button: Movement
Other parts For YTH20K46, 96043027700, 2017-11
1 W/O DESCRIPTION HONDA GCV160-LABHH FOR SERVICE & PARTS 1-800-426-7701
Engine Kohl Model No. KT715-3016 (585445801) 		000000000
2 MUFFLER 589818701
9 KEEPER 501832602
12 PULLEY 586728901
15 FUEL TANK 589900501
18 CAP 585124801
20 THROTTLE CONTROL 532182937
21 SCREW 532416358
22 COMMA*RPL.PAR 532187767428 532191596
28 HOSE 587044820
29 SPARK ARRESTER KIT 532137180
37 HADICOVÁ SVĚRKA 532123487
42 PODLOŽKA 539990247
45 MATICE 873510400
62 SHIELD 532434017
69 GASKET MUFFLER 532186054
70 TUBE 583954801
71 TUBE 583954501
79 SCREW 532192334
81 TRUBKA 532148456
82 PLUG 532428287
85 BOLT 501606501
90 SCREW 817000616
91 BUSHING 532187495
92 SCREW 817120616
102 SCREW 817000512
110 VALVE ASSY 532414118
111 PURGE LINE CARB 532414119
