Spare parts > Husqvarna > TRACTORS/RIDE MOWERS > TC 238 TC 238, 96051016301, 2017-09 > ENGINE
Back to
ENGINE
TC 238 TC 238, 96051016301, 2017-09
Hover mouse on parts list
Wheel: Zoom, left button: Movement
Other parts For TC 238, 96051016301, 2017-09
1 W/O DESCRIPTION HONDA GCV160-LABHH FOR SERVICE & PARTS 1-800-426-7701
ENGINE KAWA MODEL NO. FR600V-AS11 (581477001) 		000000000
2 MUFFLER 589818701
9 KEEPER 501832602
11 CLUTCH 587241601
12 PULLEY 532405097
15 TANK 581290101
18 HUB CAP 532430220
20 CABLE 532412165
21 SCREW 532416358
22 CHOKE CONTROL 532189541
28 HOSE 587044860
29 SPARK ARRESTER KIT 532137180
37 HADICOVÁ SVĚRKA 532123487
41 WASHER 532126197
42 PODLOŽKA 539990247
45 MATICE 873510400
62 SHIELD 532434017
69 GASKET 532165391
70 TUBE 581881101
71 TUBE 581881001
81 TRUBKA 532148456
85 BOLT 501606601
86 NUT HEX FLANGE TOPLOCK 532184362
90 SCREW 817000616
92 SCREW 817120616
96 PODLOŽKA 819091416
97 SCREW 817670412
102 SCREW 817000512
