DIN DINO (DK) (1990)

Hover mouse on parts list

Wheel: Zoom, left button: Movement

Other parts For DINO (DK) (1990)

1	Blade Disc	1111-9025-01
2	Tornado Blades	1111-9021-01
4	Washer	1111-0020-00
6	Washer	9696-0011-01
7	Screw	9987-5232-16
10	Blade Hub	1111-9023-01
11	Key	9600-0014-00
17	Wheel	1111-2656-01
18	Spring	1111-9035-01
19	Spring	1111-1589-01
20	Washer	1111-9042-01
21	Washer	9699-0069-02
22	Wheel Axle	1111-1590-01
23	Hub Cap	1111-1335-01
25	Washer	9699-0056-02
26	Screw 35 mm	9997-0835-12
27	Washer	9683-0030-02
28	Nut	9799-0831-02
31	Handlebar Clamp	1111-3017-01
32	Pivot rod	1111-1532-01
33	Washer	9670-0203-00
34	Knob	1111-0035-01
36	Washer	9699-0025-02
37	Screw	9899-3545-12
38	Cable Holder	1111-2018-01
39	Screw	9836-9216-12
40	Handlebar-lower part	1111-1702-01
41	Handlebar-Upper Part	1111-2005-01
44	Side Guard	1111-1529-01
45	Washer	1111-1593-01
46	Chassis, Yellow	1111-1644-02
48	Throttle Cable	1111-2366-01
50	Lock Nut	9747-0631-02
51	Screw	9948-0645-16
67	Spring	1111-2375-01
99	Label Kit	1111-2233-01
