Spare parts > STIGA > Lawn Mower > MULTICLIP MULTICLIP (1990) [11-3211-15] > Walkbehind
Back to
Walkbehind
MULTICLIP MULTICLIP (1990) [11-3211-15]
Hover mouse on parts list
Wheel: Zoom, left button: Movement
Other parts For MULTICLIP (1990) [11-3211-15]
1 Blade Bar Assy 1111-1603-01
2 Blade Kit (Mulcher) 1111-9049-01
3 Screw 9997-0816-16
4 Nut 9747-0831-02
6 Screw 9987-5238-12
7 Washer 9696-0011-01
10 Blade Hub 1111-9054-01
11 Key 9600-0014-00
17 Wheel 1111-2656-01
18 Spring 1111-1589-02
19 Spring 1111-1589-01
20 Washer 1111-9042-01
21 Washer 9699-0069-02
22 Wheel Axle 1111-1590-01
23 Hub Cap 1111-1335-01
25 Washer 9699-0056-02
26 Screw
30 mm 		9997-0830-16
27 Washer 9683-0030-02
28 Nut 9799-0831-02
31 Handlebar Clamp 1111-3017-01
32 Pivot rod 1111-1532-01
33 Washer 9670-0203-00
34 Knob 1111-0035-01
36 Washer 9699-0025-02
37 Screw 9899-3545-12
38 Cable Holder 1111-2018-01
39 Screw 9836-9216-12
40 Handlebar-lower part 1111-1702-01
41 Handlebar-Upper Part 1111-2005-01
44 Side Guard 1111-1529-01
46 Chassis 1111-1881-01
48 Throttle Cable 1111-2366-01
50 Lock Nut 9747-0631-02
51 Screw 9948-0645-16
67 Spring 1111-2375-01
99 Label Kit 1111-2233-02
