Spare parts > STIGA > Lawn Mower > MULTICLIP PRO 48 MULTICLIP PRO 48 (1999) > Walkbehind
Back to
Walkbehind
MULTICLIP PRO 48 MULTICLIP PRO 48 (1999)
Hover mouse on parts list
Wheel: Zoom, left button: Movement
Other parts For MULTICLIP PRO 48 (1999)
1 Blade Hub 1111-9070-01
3 Key 9600-0014-00
4 Washer 9699-0056-02
5 Nut 9799-0831-02
6 Nut 9747-0831-02
7 Screw 9987-5251-12
8 Washer 9696-0011-01
9 Engine Mounting 1111-2460-01
10 Wheel 1111-0817-04
11 Ball Bearing 9549-0015-00
12 Seal Grease 1111-0466-00
13 Spring 1111-3060-01
15 Hub Cap 1111-1506-01
17 Washer 9699-0037-02
18 Flat washer 9699-0100-02
20 Front Axle 1111-3082-01
21 Clamp 1111-1504-01
22 Screw 9943-0612-16
24 Locking washer 9675-0012-02
25 Rod 1111-1829-01
26 Rear axle 1111-3080-01
27 Spring 1111-1842-01
28 Holder 1111-1844-01
29 Screw 9943-0510-16
30 Handle Attachment,Lh 1111-1483-01
31 Handle Attachment,Rh 1111-1484-01
32 Plug 1111-1485-01
33 Screw 9942-0820-16
34 Adjusting Plate 1111-1500-01
36 Lever 1111-1839-01
37 Knob 9403-0036-70
38 Spacer 1111-1519-02
39 Screw 9997-0830-16
42 Nut 9739-0831-22
43 Screw 9959-0816-16
44 Nut 9799-0831-02
45 Handlebar Lower Part 1111-2134-01
46 Handlebar-Upper Part 1111-2974-01
47 Washer 9699-0035-02
48 Locking Knob 1482-0163-01
50 Chassie 1111-2456-01
51 Handle 9403-0037-70
52 Screw 9943-0516-16
55 Screw
L = 35 mm 		9997-0835-12
56 Nut 9799-0831-02
59 Washer 9699-0062-02
60 Shoulder Bolt 1111-2454-01
61 Isolation Washer 1111-2453-01
62 Rubber Damper 1111-2452-01
63 Throttle Control 1111-3253-01
64 Lock Nut 9747-0631-02
65 Screw
L = 60 mm 		9948-0660-16
66 Cable Holder 1111-2018-01
67 Screw 9836-9216-12
69 Blade 1111-9075-01
70 Control Handle (Eng.Brake 1111-2953-01
71 Cable, Thread Engine Brake 1111-2968-01
72 Cable Holder 1111-2969-01
73 Screw
L = 45 mm 		9948-0645-16
74 Eye Link 1111-3063-01
99 Labels Kit 1111-2893-03
