Spare parts > STIGA > Lawn Mower > MULTICLIP PRO 51 S MULTICLIP PRO 51 S (2002) > Chassis
Back to
Chassis
MULTICLIP PRO 51 S MULTICLIP PRO 51 S (2002)
Hover mouse on parts list
Wheel: Zoom, left button: Movement
Other parts For MULTICLIP PRO 51 S (2002)
1 Blade Hub 1111-3381-01
4 Washer 9699-0056-02
5 Nut 9799-0831-02
6 Nut 9747-0831-02
7 Screw 9987-5257-12
8 Washer 9696-0011-01
9 Engine Mounting 1111-3323-01
10 Shoulder Bolt 1111-2454-01
11 Isolation Washer 1111-2453-01
12 Rubber Damper 1111-2452-01
13 Rubber Tube 1111-2925-01
14 Washer 9699-0062-02
30 Handle Attachment,Lh 1111-1483-01
31 Handle Attachment,Rh 1111-1484-01
32 Plug 1111-1485-01
33 Screw 9942-0820-16
34 Adjusting Plate 1111-1500-01
43 Screw 9959-0816-16
44 Nut 9799-0831-02
45 Handlebar Lower Part 1111-2134-01
46 Handlebar-Upper Part 1111-2974-01
47 Washer 9699-0035-02
48 Locking Knob 1482-0163-01
49 Cable Holder 1111-2018-01
50 Chassis, Yellow 1111-3196-01
51 Spring 1111-2455-01
52 Screw 9943-0610-16
54 Screw
L = 55 mm 		9997-0855-12
55 Screw
L = 30 mm 		9997-0830-16
59 Screw 9836-9216-12
60 Panel 1111-2182-01
61 Lever 1111-2089-01
62 Knob 9403-0036-70
63 Spacer 1111-2090-01
64 Sleeve 1111-2181-01
65 Spring 1111-2183-01
66 Screw
L = 30 mm 		9948-0630-16
67 Screw
L = 60 mm 		9948-0660-16
68 Nut 9799-0831-02
69 Lock Nut 9747-0631-02
70 Blade 1111-9109-01
72 Cable, Thread Engine Brake 1111-2968-05
73 Control Handle (Eng.Brake 1111-2953-01
74 Lock Nut 9747-0631-02
76 Screw
L = 40 mm 		9948-0640-16
77 Lock Nut 9747-0631-02
78 Cable Holder 1111-2969-01
80 Throttle Cable 1111-1993-07
81 Nut 9739-0631-22
82 Spring 1482-0160-01
83 Eye Link 1111-3063-01
90 Tubular Frame 1111-3399-01
91 Plug 9403-0043-70
92 Screw 9997-0635-12
93 Nut 9746-0631-12
94 Ring Nut 9403-0113-01
99 Labels Kit 1111-2893-03
