TORNADO 535 TORNADO 535 (1989) [11-2225-15]

Hover mouse on parts list

Wheel: Zoom, left button: Movement

Other parts For TORNADO 535 (1989) [11-2225-15]

1	Ventilator Assy.	1111-9024-01
2	Tornado Blades	1111-9021-01
4	Screw	9987-5251-12
5	Washer	9696-0011-01
6	Spacer	1111-0400-00
7	Blade Hub	1111-9023-02
8	Key	9600-0014-00
12	Screw 35 mm, 2225	9997-0835-12
13	Washer	9683-0030-02
14	Nut	9799-0831-02
15	Washer 2225	9699-0056-02
17	Screw	9849-7909-16
20	Chassis 2225, 2322, 2727	1111-1907-01
21	Rivet	9632-0450-00
22	Stay	1111-1733-01
24	Starlock	9675-0024-00
25	Side Guard	1111-1265-01
26	Attachment-R.H.	1111-1513-01
27	Attachment-L.H.	1111-1266-01
28	Adjusting Plate	1111-1019-01
31	Tension Rod	1111-1015-02
32	Tube	1111-1014-02
33	Nut	9739-0831-22
35	Screw	9959-0816-16
36	Screw	9997-0816-16
41	Locking handle	1111-1016-01
42	Pin	9595-0235-00
43	Plastic Plate	1111-1020-01
44	Handlebar Lower Part	1111-2165-01
45	Handlebar-Upper Part	1111-2004-01
46	Handle Bolt Kit (2 Pcs)	1111-9030-02
47	Reinforcement	1111-0178-00
51	Washer	9699-0025-02
52	Screw	9899-3551-12
53	Control handle	1111-1999-01
54	Spring	1482-0160-01
55	Control Wire	1111-1993-04
56	Throttle Cable 2112, 2712	1111-2365-02
59	Screw	9948-0645-16
60	Nut	9799-0631-02
61	Nut	9739-0631-22
63	Control plate	1111-2011-01
66	Cable Holder	1111-2018-01
67	Ejection Shield 2712, 2535, 2827	1111-1653-01
68	Rubber plug	9403-0040-00
69	Circlip	9652-0005-04
70	Pivot Pin	1111-1648-01
71	Spring	1111-1649-01
72	Screw	9836-9216-12
98	Heat protection 2225, 2322, 2727,2827	1111-2246-01
99	Cable Holder 2712, 2827	1111-1936-01
