STIGA
>
Lawn Mower
>
TORNADO 535 TORNADO 535 (1989) [11-2225-55]
>
Wheel Suspension
Back to
TORNADO 535
TORNADO 535 (1989) [11-2225-55]
Wheel Suspension
TORNADO 535
TORNADO 535 (1989) [11-2225-55]
Hover mouse on parts list
Wheel:
Zoom, left button:
Movement
Other parts
For
TORNADO 535 (1989) [11-2225-55]
1
Nut
9739-0831-22
3
Wheel Shaft
1111-1269-01
4
Slotted Pin
9595-0182-00
6
Bushing
1111-2057-01
7
Hole Plate
1111-0497-00
8
Washer
9699-0108-02
10
Axle Mounting
1111-1268-01
11
Control Lever
1111-1337-01
12
Washer
9694-0001-00
13
Bolt
1111-0545-00
20
Starlock
9675-0017-02
22
Front Wheel
1111-1271-02
23
Traction Wheel Plate
1111-1274-02
24
Hub Cap
1111-1181-01
31
Washer
9699-0069-02
32
Wheel Cover
1111-1180-03
35
Spring-Wheel Axle
1111-1138-01
40
Wheel
1111-2665-01
41
Ball Bearing
1111-9047-01
42
Outer Ring
1111-1184-01
50
Transmission assy
1111-2030-01
51
Pin
1111-2382-02
55
V-Belt
1111-9053-01
56
Blade Holder
1151-0589-02
57
Key
9600-0014-00
58
Screw
2225, 2712
9907-0610-16
60
Protection Cover
2225, 2712
1111-2033-01
62
Guard
2225, 2712
1111-2111-01
64
Support
1111-1955-01
65
Screw
2535 - 2 st
9942-0512-16
66
Flat washer
2225, 2712
9699-0100-02
70
Transmission Cover (Yello
1111-1666-01
71
Screw
9848-8013-16
74
Spring
1111-2034-01
75
Control Wire
1111-1993-04
