STIGA
>
Front Mowers
>
PARK 121M PARK 121M (2000) [13-2915-23]
>
Transmission
Back to
PARK 121M
PARK 121M (2000) [13-2915-23]
Transmission
PARK 121M
PARK 121M (2000) [13-2915-23]
Hover mouse on parts list
Wheel:
Zoom, left button:
Movement
Other parts
For
PARK 121M (2000) [13-2915-23]
1
Belt Tensioner
1134-3014-01
2
Screw
9959-0820-16
3
Nut
9739-0831-22
4
Bearing Box Assy
1134-3841-01
5
Ball Bearing
9549-0019-00
6
Spacer
1134-0051-05
7
Ball Bearing
9549-0020-00
8
Bearing Cover
1134-3768-01
9
Spacer
1134-3725-01
13
Screw
9997-0820-16
14
Nut
9747-0831-02
16
Blade Shaft
1134-4600-02
17
Blade Shaft
1134-3767-01
22
Blade Bar Assy (121M)
Sats 3 st/pkg of 3
1134-9051-01
23
Blade kit
2 knivar/2 blade tips
1134-9053-01
24
Shear Bolt Kit
6 bultar/6 bolts+nuts
1134-9054-01
26
Screw
9997-0816-16
27
Nut
9712-0831-02
28
Screw
9945-0825-16
32
V-Belt
9504
1134-9045-01
35
Belt Pulley
1134-3419-01
36
Key
9600-0150-03
37
Nut
1134-4775-01
38
Washer
9699-0030-02
39
Toothed Belt Pulley
1134-3679-02
40
Plate-Belt Pulley
1134-3598-01
41
Reinforcement
1134-3597-01
42
Screw
9997-0630-12
43
Lock Nut
9747-0631-02
44
Washer
9699-0104-02
45
Toothed Belt Pulley
1134-3679-01
48
Screw
9997-0625-16
49
Toothed Belt
9585-0085-00
50
Key
9600-0150-02
