STIGA
>
Front Mowers
>
PARK 125 COMBI PRO PARK 125 COMBI PRO (2005) [13-2936-18]
>
Controls
Back to
PARK 125 COMBI PRO
PARK 125 COMBI PRO (2005) [13-2936-18]
Controls
PARK 125 COMBI PRO
PARK 125 COMBI PRO (2005) [13-2936-18]
Hover mouse on parts list
Wheel:
Zoom, left button:
Movement
Other parts
For
PARK 125 COMBI PRO (2005) [13-2936-18]
1
Height Adjust Quadrant
1134-5447-01
2
Screw
9959-0816-16
3
Nut
9739-0831-22
4
Handle
1134-5503-01
5
Push Button
1134-5443-01
6
Spring
1134-5445-01
7
Push rod
1134-5444-01
8
Catch Assy
1134-5440-01
9
Screw
9959-0840-16
10
Spacer
1134-1565-13
11
Washer
9699-0028-02
12
Nut
9747-0831-02
13
Rear Axle Assy-Manual (Yellow)
1134-6155-01
14
Bearing Half
1134-5469-01
15
Bearing Plate-Rear
1134-5471-01
16
Screw
9997-0845-12
17
Nut
9739-0831-22
18
Push rod
1134-5473-01
19
Elbow Link
9570-0002-00
20
Nut
9739-0831-22
21
Pivot Arm
1134-5855-01
22
Pivot bracket
1134-5858-01
23
Screw
9997-0880-16
24
Washer
1134-5127-01
26
Screw
9959-0816-16
27
Nut
9739-0831-22
28
Front Axle (Grey) 7-14
1134-5427-01
29
Bearing Half
1134-5469-01
30
Bearing Plate-Front
1134-5846-01
31
Screw
9997-0845-12
32
Nut
9739-0831-22
33
Washer
9699-0087-02
34
Nut
9747-0831-02
