GARDEN 1072E GARDEN 1072E (1996) [13-2328-59]

Hover mouse on parts list

Wheel: Zoom, left button: Movement

Other parts For GARDEN 1072E (1996) [13-2328-59]

1	Fuel Tank	1134-3090-01
2	Fuel Tank Cap	1134-2877-02
3	Fuel Shut-Off Valve	1134-3224-01
4	Grommet	1134-3225-01
5	Tank Support	1134-3221-01
6	Nut	9747-0831-02
7	Engine Pulley Tillbehör/Accessory	1134-3651-01
8	Clutch Lever	1134-3141-01
9	Spacer	1134-3144-01
10	Screw	9849-8013-16
11	Screw	1134-0240-00
12	Washer	1134-3147-01
13	Washer	9699-0056-02
14	Nut	9739-0831-22
15	Tension Roller (Black)	1134-9027-01
16	Nut	9739-1031-22
17	V-Belt =9585-0057-00	1134-9013-01
18	Spring	1134-1578-01
19	Belt Stirrup	1134-2086-01
20	Screw	9997-0830-16
21	Transaxle (915-011D) Peerless 915-011C	1134-3157-01
22	Spacer Tube	1134-3154-01
23	Screw	9997-0815-02
24	Washer	9699-0090-02
25	Belt Pulley	1134-3182-01
26	Key	9600-0050-00
27	Circlip	9650-0016-04
28	Pedal Bracket	1134-3106-01
29	Screw	9898-0820-16
30	Control Lever	1111-0062-01
31	Knob	1111-0040-02
32	Washer	9694-0001-00
33	Gas Wire	1134-1597-09
34	Wire Clamp	1134-3240-01
35	Gear Shifter	1134-3112-02
36	Lever Handle	1134-3193-01
37	Spacer	1134-1565-01
39	Gear Shifter Plate	1134-3160-01
40	Locking washer	9675-0012-02
41	Gear Shifter Lever	1134-3109-01
42	Screw	9987-5016-16
43	Washer	9699-0060-02
44	Pedal	1134-3169-01
45	Pedal Rubber	1134-0269-00
46	Bushing	1111-0158-00
47	Spacer	1134-3047-01
48	Spring	4231-0013-00
49	Control Rod	1134-3146-01
50	Split pin	9599-0067-02
51	Elastic Pin	9598-0002-02
52	Plastic Housing	1134-3178-01
53	Parking Brake Lever	1134-3179-01
54	Spring	1134-3180-01
55	Screw	9997-0520-16
56	Nut	9747-0531-02
57	Screw	9987-5338-12
62	Key	9600-0250-00
65	Oil Drain Pipe	1134-2212-01
66	Plug	1134-0995-01
67	O-Ring	9404-0020-00
68	Gasket	1134-0997-01
73	Rim	1134-3171-01
74	Tyre 15 x 6.00-6	9545-0118-00
75	Valve Assy.	9545-0500-00
76	Bolt	1134-3170-01
77	Shift Rod	1134-3200-01
80	Screw	9997-0855-12
82	Fuel Line	1134-2975-04
83	Hose clamp	1134-3499-01
7A	Screw	9997-1450-16
