Spare parts
>
Mountfield
>
Trimmer/Brushcutter
>
MB 22CX MB 22CX (2005)
>
Brush Cutter Drive Shaft
Back to
MB 22CX
MB 22CX (2005)
Brush Cutter Drive Shaft
MB 22CX
MB 22CX (2005)
Hover mouse on parts list
Wheel:
Zoom, left button:
Movement
Other parts
For
MB 22CX (2005)
2
Fixed Plate
MB22CX
1911-3761-01
3
Insulator
MB22CX
1911-3762-01
5
Throttle Cable
MB22CX
1911-3911-01
6
Cover
MB22CX
1911-3763-01
7
Ground wire
MB22CX
1911-3764-01
8
Switch
MB22CX
1911-3918-01
9
Housing Assy Red
MB22CX
6980325
10
Fuel Tank Assy
Pos 11, 12, 34 incl. _ MB22CX
1911-3766-01
11
Fuel Pick-Up
MB22CX
1911-3767-01
12
Fuel Tank Cap
MB22CX
1911-3912-01
13
Spring
MB22CX
1911-3769-01
14
Throttle Trigger
MB22CX
1911-3914-01
15
Lower Tube
MB22CX
1911-3916-01
16
Stone Guard
Pos 17 incl. _ MB22CX
1911-3896-01
17
Line Cutter Blade
MB22CX
1911-3772-01
18
Front Handle Assy
MB22CX
1911-3897-01
19
Cutting Head Assy
Pos 20 - 22 incl. _ MB22CX
1911-3895-01
20
Spring
MB22CX
1911-3898-01
21
Line Inlet
MB22CX
1911-3899-01
22
Knob (Lh-Thread)
MB22CX
1911-3757-01
23
Gear case assy
MB22CX
1911-3900-01
24
Stabilizer Bowl
MB22CX
1911-3906-01
25
Clearing Blade 3T
3T _ MB22CX
1911-3920-01
26
Cutting Head Key
MB22CX
1911-3907-01
27
Harness
MB22CX
1911-3908-01
28
Harness Support
MB22CX
1911-3909-01
29
Label
MB22CX
1911-3910-01
30
Clutch Drum
MB22CX
1911-3780-01
31
Clutch
MB22CX
1911-3779-01
32
Tube Joint Assy
MB22CX
1911-3777-01
33
Shaft sleeve
MB22CX
1911-3776-01
34
Grommet
MB22CX
1911-3929-01
35
Screw
MB22CX
1911-3013-01
36
Screw
MB22CX
1911-4262-01
37
Washer
MB22CX
1911-4263-01
38
Screw
MB22CX
1911-4264-01
39
Screw
MB22CX
1911-4265-01
14A
Safety Lever
1911-3915-01
15A
Upper Tube
1911-3917-01
16A
Screw
9865-0520-16
16B
Nut
9747-0531-02
18A
Screw
9865-0530-16
18B
Nut
9747-0531-02
19A
Cutting Line (130M-2.0Mm)
1911-9007-04
23A
Collar
1911-3901-01
23B
Upper Ring Nut
1911-3902-01
23C
Lower Ring Nut
1911-3903-01
23E
Nut
1911-3905-01
23F
Screw
9997-0535-12
23G
Washer
9699-0024-02
23H
Nut
9739-0531-22
23I
Screw
9865-0512-16
23J
Washer
9683-0015-02
28A
Screw
9865-0510-16
28B
Nut
9747-0531-02
32A
Screw
9939-0630-12
32B
Nut
9799-0631-02
32C
Screw
9997-0635-12
