Spare parts > Castelgarden > Chainsaw > XC 36 XC 36 (2007) > Crankcase-trim group
Back to
Crankcase-trim group
XC 36 XC 36 (2007)
Hover mouse on parts list
Wheel: Zoom, left button: Movement
Other parts For XC 36 (2007)
2 Tank Cap 4252010
4 Oil Pump Assy 4252220
5 Spacer 3744790
6 Screw 2123020
7 Retainer 3614810
8 Bar 14inch 123900205/0
9 Screw 2653470
10 Screw 123878001/0
11 Chain Tightener Block 3641970
12 Oil Supply Cap 3741360
13 Insert 3614930
14 Oil Tube Assy 3L4353090/1
15 Bar Plate 323311002/0
16 Chain 14inch 4113702
17 Clutch Housing Assy Red 4252333
18 Fuel Line 3786050
19 Intake Filter 4253290
20 Nut 2670270
21 Screw 323650100/0
22 Breather Valve Assy 4253680
23 Screw 2123060
24 Chain Cover 14inch 4181297
