Spare parts > ST S p A > Lawn Mower > HERKULES MB 482 SH COMBI HERKULES MB 482 SH COMBI (2001) > Deck
Back to
Deck
HERKULES MB 482 SH COMBI HERKULES MB 482 SH COMBI (2001)
Hover mouse on parts list
Wheel: Zoom, left button: Movement
Other parts For HERKULES MB 482 SH COMBI (2001)
1 Blade 1111-9090-01
2 Screw 9987-5251-12
3 Washer 9696-0011-01
4 Blade Hub 1111-9070-01
5 Key 9600-0014-00
8 Chassie (Red) 1111-3090-04
9 Flap Attachment-Black 1111-2793-02
10 Screw 9947-0616-16
11 Spring 1111-2792-01
12 Stone Guard, Black 1111-3283-02
15 Rear Attachment (Combi 48-55) 1111-3335-01
16 Attachment L.H. 1111-3236-01
17 Attachment R.H. 1111-3237-01
18 Screw 9836-9520-12
19 Screw 9838-9522-12
22 Screw 9955-3732-12
25 Collector-Upper Part Black 1111-2840-02
26 Cover 1111-2764-01
27 Collecting Bag 1111-2844-01
28 Wire Clamp 1111-2843-01
29 Flat washer 9699-0100-02
35 Mulch Plug (Combi 48) 1111-3333-01
