HERKULES ME 412 HERKULES ME 412 (2000)

Hover mouse on parts list

Wheel: Zoom, left button: Movement

Other parts For HERKULES ME 412 (2000)

1	Yellow Deck	1117-1317-01
2	Ball Bearing	9549-0053-00
3	Flap (Black) 782 441	1111-3103-02
4	Motor Mount (Black) 782 441	1117-1318-02
5	Pin	1117-1215-01
6	Wheel	1111-3163-01
7	Wheel	1111-3238-01
8	Lever, Height Adjustment Inkl. pos 5 _ 782 441	1117-1228-01
9	Wheel Shaft	1117-1381-01
10	Wheel Plate	1117-1379-01
11	Hub Cap (Red) 782 403	1111-2815-04
12	Wheel Bolt	1111-3164-01
13	Wheel Plate	1117-1376-01
14	Hub Cap (White) 782 441	1111-2804-03
15	Fan/Bladeholder	1111-3137-01
16	Blade 782 441	1117-1273-01
17	Blade Bolt	1117-1169-01
18	Motor Holder	1111-2757-02
19	Electric Motor 1300 W _ 782 441	1117-1366-01
20	Fan	1117-1370-01
21	Screw 782 403	9898-0855-12
22	Nut	9716-0831-02
23	Grass Bag Cover, Yellow Inkl. pos 24	1117-1345-01
24	Cover	1111-2764-01
25	Collector-Lower Part L.H.	1111-3106-01
26	Collector-Lower Part R.H.	1111-3116-01
27	Knob	1117-3194-01
28	Washer	9699-0028-02
29	Screw	9847-7909-16
30	Screw	9836-9516-12
31	Spring	1111-2792-01
32	Motor Cover (Black)	1117-1305-01
33	Screw	9836-9116-12
34	Condensor (16 Uf) 16 µF _ 782 441	9400-0265-00
35	Screw	1117-3226-01
36	Washer	1117-1175-01
37	Washer	1111-3136-01
38	Cable Holder	9579-0008-00
39	Upper Handle with Switch	1117-3209-01
40	Handle Tube-Left	1117-3206-01
41	Washer	9699-0062-02
42	Washer	9694-0003-00
43	Wheel Shaft	1117-1380-01
44	Washer	1117-1356-01
45	Washer	9699-0037-02
46	Cap	1117-1371-01
47	Sector, Height Adjustment	1117-1382-01
48	Assy Kit	1117-3220-01
49	Nut	9799-0831-02
40A	Handle Tube-Right	1117-3207-01
