Spare parts
>
ST S p A
>
Front mowers
>
SOLET SOLETT (SF) (1990) [13-2836-73]
>
Steering Seat
Back to
SOLET
SOLETT (SF) (1990) [13-2836-73]
Steering Seat
SOLET
SOLETT (SF) (1990) [13-2836-73]
Hover mouse on parts list
Wheel:
Zoom, left button:
Movement
Other parts
For
SOLETT (SF) (1990) [13-2836-73]
1
Steering wheel
1134-1967-01
2
Locating Pin
9595-0262-00
3
Washer
0.5 mm
9699-0103-02
5
Steering Rod
1134-1424-01
6
Bearing
1134-1901-01
8
Steering Pulley
1134-1933-01
9
Bushing
1134-0041-01
10
Steering Pulley
1134-9025-01
11
Bracket
1134-3022-01
12
Screw
9942-1030-16
13
Steering Wire
1134-9023-01
14
Nut
9747-0831-02
15
Washer
9699-0090-02
16
Spring
1134-1310-01
17
Screw
9959-0816-16
18
Nut
9739-0831-22
19
Bearing
1134-9024-01
20
Washer
1134-0341-01
21
Circlip
9650-0020-04
22
Nut
9799-0831-02
23
Steering Pulley
1134-1500-01
24
Elbow Link
9570-0002-00
25
Tie Rod
1134-1427-01
30
Screw
9959-0825-16
32
Control Rod
1134-0022-00
33
Starlock
9672-0004-02
34
Rod
1134-2163-01
35
Spacer
1134-2166-01
42
Seat Bracket-Yellow
1134-3252-02
43
Tube
1134-2846-01
44
Axle
1134-1883-01
45
Seat spring
1134-0015-00
48
Spring
1134-1652-01
49
Seat Rod
1134-0050-00
50
Nut
1134-0493-00
52
Tie Bar
1134-1650-01
53
Starlock
9675-0017-02
54
Seat Adapter
1134-2961-01
55
Screw
9898-0820-16
56
Screw
9988-3616-16
57
Washer
9699-0062-02
58
Knob
1134-1711-01
63
Seat Attachment-R.H.
1134-3618-01
64
Seat attachment-L.H.
1134-3618-02
65
Seat Sears Sa 1216 (9407-0003-01) 20
1134-0800-06
67
Shaft
1134-2454-01
68
Lock washer
9672-0006-02
69
Shaft
1134-2847-01
