Spare parts > Husqvarna > TRACTORS/RIDE MOWERS > TS 242TXD TS 242TXD, 96041043500, 2019-07 > ENGINE
Back to
ENGINE
TS 242TXD TS 242TXD, 96041043500, 2019-07
Hover mouse on parts list
Wheel: Zoom, left button: Movement
Other parts For TS 242TXD, 96041043500, 2019-07
1 W/O DESCRIPTION HONDA GCV160-LABHH FOR SERVICE & PARTS 1-800-426-7701
Briggs&Stratton 44U677-0018-B5 (597367101) 		000000000
2 MUFFLER 589818701
9 KEEPER 501832602
11 CLUTCH 587255001
12 PULLEY 586899601
15 FUEL TANK 532193499
18 CAP 584248702
20 CONTROL THROTTLE 532424341
21 SCREW 596321701
28 LINE.FUEL.64"REAR.EMIS 532401135
29 SPARK ARRESTER KIT 532137180
37 HADICOVÁ SVĚRKA 532123487
41 WASHER 532126197
42 WASHER 596238901
45 LOCK NUT 596133601
62 SHIELD 532434017
69 GASKET 532165391
70 TUBE 581881101
71 TUBE 581881001
79 SCREW 596134202
81 TRUBKA 532148456
82 PLUG 532428287
84 SCREW 817060620
85 BOLT 501606701
90 SCREW 817000616
91 BUSHING
(532 19 74-95) Bushing, 1.375 OD, Hexco2210 		532187495
102 SCREW 817000512
105 SHIELD
Shield Chassis LH 		591204902
106 SHIELD
Shield Chassis RH 		591205002
108 COVER 592727101
116 KNOB - SHIFT 539132624
