Spare parts
Everything for your machines
Spare parts
>
Husqvarna
>
ZERO TURN: COMMERCIAL
>
MZ 48 MZ 48
>
IGNITION SYSTEM
Back to
MZ 48
MZ 48
IGNITION SYSTEM
MZ 48
MZ 48
Hover mouse on parts list
Wheel:
Zoom, left button:
Movement
Other parts
For
MZ 48
1
CONSOLE
539107593
2
SERVICE KIT
598664901
3
FITTING
576469201
4
LANKO PLYNU
For 96766590100
539112438
5
CABLE
539113458
6
GROMMET
539105245
7
GROMMET
576618201
8
ODVZDUŠNĚNÍ NÁDRŽE
576618101
9
HOOK
For 96766590101, 97045570100, 97045560100
510064002
10
CAP
575018101
11
BATTERY
For 96766590101, 97045570100, 97045560100
539102463
12
BRACKET
For 96766590101, 97045570100, 97045560100
593634404
13
LANKO
588030701
14
LANKO
588030801
15
SWITCH
574455401
16
SWITCH
582107602
17
SWITCH
532109553
18
SWITCH
For 96766590100
539113792
19
SPRING
539102845
20
PALIVOVÁ HADIČKA
For 96766590100
586123903
21
KEY
574455501
22
KNOB ROUND BALL
539133049
23
HOSE
CUT TO FIT
587044564
24
HOUR METER
For 96766590101, 97045570100, 97045560100
594919101
25
PLATE
592877402
26
SUPPORT
539131671
27
NUT CAP
539103178
28
STUD
539102502
29
PLATE
581223001
30
CLAMP
575436501
31
TERMINAL COVER
For 96766590101, 97045570100, 97045560100
532435395
32
PODLOŽKA
819111116
33
WASHER
819070818
34
WASHER
810030500
35
BOLT
For 96766590101, 97045570100, 97045560100
595901601
36
SCREW
874780512
37
SCREW
574822701
38
SCREW
817490516
39
SCREW
539990411
40
WINGNUT
For 96766590101, 97045570100, 97045560100
539990997
41
NUT
For 96766590101, 97045570100, 97045560100
594944401
42
NUT
539976977
43
DECAL
For 96766590101, 97045570100, 97045560100
574841103
44
LOCK NUT
For 96766590101, 97045570100, 97045560100
596040801
45
SCREW
For 96766590101, 97045570100, 97045560100
596582801
46
BOLT
For 96766590101, 97045570100, 97045560100
595316801
47
GROMMET
For 96766590101, 97045570100, 97045560100
539105974
48
WASHER
For 96766590101, 97045570100, 97045560100
596133301
49
NUT
For 96766590101, 97045570100, 97045560100
521996502
50
BRACKET
For 96766590101, 97045570100, 97045560100
594037402
51
HADICE
For 967262801-00
587044536
52
HADICE
For 967262801-00, 96766590100
587044527
53
FILTER
For 967262801-00
532414114
54
BRACKET
For 967262801-00
575242701
HARNESS
For 96726270100, 96726280100, 96766590100, 96766590101, 97045560100, 97045570100
585999702
