Spare parts > Husqvarna > TRACTORS/RIDE MOWERS > TC 138 TC 138 > ENGINE
Back to
ENGINE
TC 138 TC 138
Hover mouse on parts list
Wheel: Zoom, left button: Movement
Other parts For TC 138
1 W/O DESCRIPTION HONDA GCV160-LABHH FOR SERVICE & PARTS 1-800-426-7701
For 96051017900, Engine Briggs Model No. 31R577-0027-B5 (597359601 		000000000
2 MUFFLER
For 96051020000 		590645301
9 KEEPER
For 96051020000 		596501502
10 ENGINE
For 96051020000, Husqvarna Model HV 452CC. Engine ipl available separately. 		598694001
12 PULLEY 586478501
15 FUEL TANK ASSY
For 96051017900, EPA TANK 		597952201
18 HUB CAP 532430220
20 CONTROL
For 96051012400, 96051012401, 96051012402, 96051020000 		532183897
21 SCREW 596321701
28 HADICE 532137040
29 SPARK ARRESTER KIT 532137180
37 HADICOVÁ SVĚRKA 532123487
42 WASHER 596238901
45 NUT
For 96051020000 		593356401
69 GASKET
For 96051020000 		590863501
79 SCREW 596134201
84 SCREW
For 96051020000 		817120616
85 BOLT 501606501
86 NUT HEX FLANGE TOPLOCK
For 96051020000 		532184362
87 BOLT
For all EXCEPT 96051012400, 96051012401 		532171877
90 SCREW 817000616
94 TUBE
For 96051020000 		590864701
96 WASHER 596135301
97 SCREW 817670412
102 SCREW 593337601
108 COVER 587179510
122 EXTENSION PIPE 532421922
138* HOSE
For 96051017900, only equipped with the EPA tank 		587044531
