Spare parts > Gardena > Husqvarna Smart System > Robotic mower SILENO life, 750 m² Robotic mower SILENO life, 750 m² > CHASSIS LOWER
Back to
CHASSIS LOWER
Robotic mower SILENO life, 750 m² Robotic mower SILENO life, 750 m² (967845307 - 4078500043625, 967845303 - 4078500043557)
Hover mouse on parts list
Wheel: Zoom, left button: Movement
Other parts For Robotic mower SILENO life, 750 m²
1 COLUMN ASSY Column Assy 590770701
2 CLIP Clip 591474201
3 PRINTED CIRCUIT ASSY Printed Circuit Assy
Main Board 		592909901
4 WIRING ASSY 536253901
5 SEALING STRIP Seal Strip 574874711
6 SEALING STRIP Seal Strip 574874710
7 SCREW ITXPANT 574450101
8 PRINTED CIRCUIT ASSY Printed Circuit Assy 592909801
9 CHASSIS 591365401
10 MOTOR KIT
Up to Serial number 1944XXXXX 		587449404
11 SCREW ITXPANT 574450101
12 WHEEL ASSY Wheel assy 590587101
13 WASHER 586210601
14 HEXAGON THIN NUT 731432401
15 HUB CAP Hub Cap 590660201
16 SENSOR ASSY Sensor Assy 593094601
17 WIRING ASSY 534189601
18 WIRING ASSY Wiring Assy 589351001
19 HOUSING 592654401
20 BATTERY 593247201
21 COVER Cover 582824901
22 SCREW ITXPANT 574450101
23 WHEEL ASSY Wheel assy 589300801
24 WIRING ASSY
Battery 		535018402
