Spare parts
>
Husqvarna
>
TRACTORS/RIDE MOWERS
>
TC 342 TC 342
>
MOWER DECK / CUTTING DECK
Back to
TC 342
TC 342
MOWER DECK / CUTTING DECK
TC 342
TC 342 (960510129 - 7393089103940)
Hover mouse on parts list
Wheel:
Zoom, left button:
Movement
Other parts
For
TC 342
1
DECK
Deck Weldmen
580973301
2
MATICE
Palnut 1/4
532423062
3
MATICE
Nut Lock Hex Flange 5/1618
873900500
5
BOLT
Bolt 5/1618
817000510
11
SCREW
Screw ThdRoll 1/420x5/8
532137729
13
BOLT
Bolt Carr Sh3/816x11/2Gr.5
872110612
14
BELT GUIDE
Keeper BeltIdler
532156085
16
MATICE
NutLock FlG 3/816unc
873900600
17
MATICE
Nut Flange LockTop
532400234
19
BEARING
Bearing Mandrel
585323901
23
SCREW
Screw Thdrol 3/816x13/4
817490628
27
BELT
V Belt Drive
532445887
32
PRUŽINA
Spring Return Deck
532446205
33
BEARING HOUSING
Mandrel Asm
532187281
34
HRÍDEL
Shaft Asm Mndrl
580854701
35
RIDE ON BLADE
Blade Mower LH
532180583
38
SCREW
Bolt Blade 7/1620x1.5Gr.8
590884001
39
PODLOŽKA
WASHER
581526501
41
PODLOŽKA
WASHER
539990247
42
SCREW
Screw 5/1618x3/4
817000512
43
PULLEY
Pulley Mandrel
532443239
45
BEARING HOUSING
Mandrel Asm.
532137152
46
WASHER
FLAT WASHER 3/8
585729901
47
SCREW
SCREW
584309301
72
CHUTE
Chute Upper
581454103
75
PULLEY
Pulley Idler Flat
532131494
76
PORT.WASHOUT
Washout Port
532415598
84
HLÍDAČ
Keeper Belt Mandre
532443235
85
RIDE ON BLADE
Blade Mower RH
532180584
86
BOLT
Bolt 3/824x1.50Gr.8
532181713
87
PODLOŽKA
Washer 3/8
539990118
88
PODLOŽKA
Washer Hard Blade
532140296
91
PODLOŽKA
Washer 13/32x11/4x12Ga.
819132012
94
BRACKET
Bracket Clutch Cable
532197250
95
SCREW
Screw 3/816x3/4
817000612
96
ROZPĚRKA
Spacer
532400271
97
PROTECTOR
Shield Idler Mower
532182061
98
ŠROUB
Stud Fastener
532195161
99
ARM
ARM SUSPENSION
532195186
100
BOLT
Bolt Shoulder
532196539
101
MATICE
Nut Crownlock 9/1618unc
873680900
102
ROZPĚRKA
Spacer Bearing Swing Plate
532402511
104
COVER
Mandrel Cover RH
581714001
105
COVER
Mandrel Cover LH
532444755
110
GEAR
Gear Output
587934801
111
GASKET
Gasket Gearcase
532436979
112
HRÍDEL
Shaft Gearcase
532443852
113
PLUG
Plug Oil
532438533
114
BREATHER
Vent Breather 1/8NPT
588170501
115
SCREW
Screw Torx#10 24x1
818031016
116
BOLT
Bolt 1/420x1.75Gr.5
872110414
117
MATICE
Nut Hex Flange 1/420unc
873900400
118
ARM
Arm Clutching
532443232
119
GEARCASE
Gearcase Subasm
532438166
120
HLÍDAČ
Keeper Belt RH
532443236
121
PODLOŽKA
Washer
532436985
124
HRÍDEL
Non Greasable Mandrel Shaft
532436986
125
BRACKET
Bracket Idler Chassis
532436994
127
BOLT
Bolt Shoulder 3/816x35/8Gr.5
532193406
128
KOLO
Wheel Gauge
532174873
129
ROD
Rod AntiSway
532443237
130
PODLOŽKA
Washer 13/32x13/16x12Ga
819131312
131
KOLÍČEK
Pin Cotter 5/16BowTieLock
532194208
143
CUTTING DECK KIT
DOOR
532438198
144
PEN
PIN
532435861
145
KROUŽEK
E-RING
532437988
146
PRUŽINA
SPRING
532445896
150
CHUTE ASSY
Chute
596012302
154
SCREW
Screw 1/420
532199855
156
SCREW
SCREW
532199855
158
RIDE ON BLADE
BLADE RH
532180425
159
REINFORCEMENT PLATE
Plate LH Side
585309405
160
REINFORCEMENT PLATE
Plate LH Front
585309505
161
REINFORCEMENT PLATE
Plate RH Front
585316005
162
REINFORCEMENT PLATE
Plate RH Side
585316105
250
PODLOŽKA
WASHER
819111212
255
BOLT
Carriage Bolt 1/420x1Gr.5
539109800
258
BOLT
Bolt Hex Wsh Hd.31618x1.19
584953901
259
CUTTING DECK
GEAR CASE KIT-Use .75 oz. Shell 460 oil (included Gear Output (key #110), Gasket Gearcase (key #111), Shaft Gearcase (key #112), Plug Oil (key #113), Vent Breather 1/8 NPT (key #114), Screw Torx (key#114), Screw Torx (key #115), Gearcase Subasm (key #119)
532448132
