HEDGE TRIMMERS
>
HG65 HG65, 953900523, Prefix 04, 2007-04
>
CLUTCH & OIL PUMP
Back to
HG65
HG65, 953900523, Prefix 04, 2007-04
CLUTCH & OIL PUMP
HG65
HG65, 953900523, Prefix 04, 2007-04
Hover mouse on parts list
Wheel:
Zoom, left button:
Movement
Other parts
For
HG65, 953900523, Prefix 04, 2007-04
1
REAR HANDLE ASSY
538242276
2
SCREW
538241077
3
SCREW
538240862
4
WIRES ASSY
538243875
5
SWITCH
538242439
6
THROTTLE TRIGGER
538242277
7
SAFETY CABLE
538242496
8
SAFETY LEVER
538242278
9
HANDLE HALF
538242273
10
HANDLE HALF
538242272
11
HANDLE LOCK PISTON
538242282
12
CONTROL LEVER
538242346
13
HANDLE LOCK
538242280
14
SCREW
538242988
15
HOUSING
538242283
16
REAR HANDLE FLANGE
538242284
17
NUT
538229524
19
PIN RETAINING SCREW
538242493
20
FRAME ASSY
538248911
21
SAFETY HANDLE
538242300
22
FRAME
538242987
23
SCREW
538111117
24
BUSH
538242305
25
SPRING
538242306
26
FRONT HANDLE
538242286
27
BLADES BRAKE ASS'Y
538242430
28
BEARING
538216404
29
GEARBOX
538249766
30
CLUTCH DRUM
538242310
31
BEARING
538235897
32
GEAR
538242312
33
GEAR BOX COVER
538242302
34
FELT SHIELD
538242314
35
NUT
538235912
36
SCREW
538236527
37
BLADES ASS'Y
538242497
38
PIN RETAINING SCREW
538242329
39
BRAKE COUPLING ASS'Y
538242318
40
BLADE BRAKE SUPPORT
538024230
41
SPRING
538242321
42
PIN RETAINING SCREW
538242319
43
CABLE GUIDE
538242316
44
BLADE BRAKE LEVER
538242320
45
GAS WIRE
538242494
46
SPRING
538242307
47
SCREW
538111117
48
SCREW
538218644
49
SCREW
538241963
