STIGA
>
Lawn Mower
>
TURBO 510S TURBO 510S (1993) [12-7218-17]
>
Chassis Transmission
Back to
TURBO 510S
TURBO 510S (1993) [12-7218-17]
Chassis Transmission
TURBO 510S
TURBO 510S (1993) [12-7218-17]
Hover mouse on parts list
Wheel:
Zoom, left button:
Movement
Other parts
For
TURBO 510S (1993) [12-7218-17]
1
Blade bar assy.
1111-1555-01
2
Blade kit
1111-9050-01
3
Nut
9747-0831-02
4
Nut
9747-0831-02
9
Fan
1111-1407-01
10
Blade Holder
1111-1554-01
11
Key
9600-0014-00
12
Circlip
9650-0038-04
14
Screw
60 mm _ 7818
9997-0860-16
15
Washer
9683-0030-02
16
Nut
9799-0831-02
20
Chassie
1111-2543-01
21
Flap (Black)
1111-2064-01
22
Pin
9594-0011-00
23
Spring
1111-1683-01
28
Collector assy
11-6971-11
29
Screw
9865-0535-16
30
Washer
9699-0018-02
31
Nut
9747-0531-02
32
Locking clutch
1111-1103-01
33
Handle
1111-1547-01
34
Collecting Bag
1111-1562-01
35
Tubular Frame
1111-1546-01
36
Retainer
1111-1591-01
37
Screw
9847-7913-16
38
Net Grass Collector
1111-1694-01
39
Starlock
9675-0008-02
40
Belt Pulley
1111-2433-01
41
V-Belt
1111-9052-01
42
Screw
9911-0612-16
44
Screw
9943-0530-16
45
Transmission Cover
1111-1537-01
48
Washer
9665-0003-00
49
Washer
1151-0590-01
56
Washer
1151-0587-01
57
Screw
9987-5264-12
58
Washer
9699-0029-02
59
Friction Disc
Incl. in 1111-9519-01
1111-1731-01
64
Transmission assy.
1111-1186-01
65
Belt Pulley
1111-1188-01
66
Spring Attachment
1111-1189-01
67
Spring Attachment
1111-1190-01
68
Screw
9943-0510-16
69
Circlip
9659-0050-04
70
Brake Spring
1134-1023-00
85
Screw
9849-7909-16
87
Key
F000-3475-00
99
Cable Holder
1111-1936-01
100
Label Kit
1111-2893-08
38A
Dust guard
1111-1682-01
