Spare parts > Castelgarden > Chainsaw > A 3535 A 3535 (2008) [202014013/08] > Housing
Back to
Housing
A 3535 A 3535 (2008) [202014013/08]
Hover mouse on parts list
Wheel: Zoom, left button: Movement
Other parts For A 3535 (2008) [202014013/08]
41 Handle Assy 183300014/0
42 Switch 123303001/0
43 Tank Cap 183790005/0
44 Intake Filter Assy 183520001/0
45 Fuel Tank-Cap Ass.Y 183790004/0
46 Throttle Lever 123315069/0
48 Throttle Cable 123066010/0
49 Safety Lever 123315070/0
50 Primer 6980242
51 Earth Cable 123065020/0
52 Stop Wire 123065021/0
53 Spring Assy 183430550/0
54 Starter Handle 3749437
55 Starter Assy Yellow 183058015/0
56 Handle 123105002/0
57 Cylinder Cover Yellow 123087013/0
58 Knob 123593504/0
59 Bushing 123160053/0
60 Grommet Air-Lever 123202001/0
61 Choke Lever 123315068/0
62 Clutch Ho. W/Br. Assy Yellow 183059010/0
63 Nut 123120006/0
64 Guide Bar 14inch 123900350/0
65 Chain 14inch 4113703
66 Chain Cover 14inch 4181297
67 Starter Pulley 183604000/0
68 Starter Spring 123430604/0
69 Starter Hub 123445267/0
70 Screw 123878108/0
