ST S p A
>
Lawn Mower
>
FLANDRIA EURO 33 EL FLANDRIA EURO 33 EL (1999)
>
Electric Walkbehind
Back to
FLANDRIA EURO 33 EL
FLANDRIA EURO 33 EL (1999)
Electric Walkbehind
FLANDRIA EURO 33 EL
FLANDRIA EURO 33 EL (1999)
Hover mouse on parts list
Wheel:
Zoom, left button:
Movement
Other parts
For
FLANDRIA EURO 33 EL (1999)
1
Blade
1111-9082-01
2
Blade Bolt
1111-2787-02
3
Fan/Bladeholder
1111-3137-01
7
Motorcover Lower-Black 2
1111-2750-02
8
Motor cover-white
4518
1111-2929-03
9
Flap-black
1111-2761-02
10
Spring
1111-2789-01
11
Screw
9838-9110-12
16
Wheel
1111-2762-01
17
Hubcap 130 (White) 2003
1111-2763-03
18
Wheel
1111-3199-01
19
Hubcap 160 (White) 2003
1111-3200-03
20
Wheelcup, White
1111-2756-03
21
Shoulderbolt 2
1111-2788-01
27
Condensor (16 Uf)
9400-0265-00
28
Washer
1111-2765-00
32
Lower Collector (Black)
1111-2760-02
33
Upper Collector (Black)
1111-2758-02
34
Cover
1111-2764-01
37
Lower Handlebar
1111-2768-02
38
Upper Handle with Switch
1111-2904-02
39
Screw
9846-7916-16
40
Cable Holder
9579-0008-00
50
Washer
1111-3136-02
