Spare parts > Jonsered > CHAIN SAWS > 670 670, CHAMP, 1994-08 > CARBURETOR DETAILS
Back to
CARBURETOR DETAILS
670 670, CHAMP, 1994-08
Hover mouse on parts list
Wheel: Zoom, left button: Movement
Other parts For 670, CHAMP, 1994-08
501216201 REAR HANDLE 501216201
501220301 PLUG WELCH 501220301
501220801 DIAPHRAGM 501220801
501220901 DIAPHRAGM 501220901
501221001 DIAPHRAGM 501221001
501221201 FUEL PUMP DIAPHRAM 501221201
501221301 FUEL PUMP 501221301
501222001 LEVER 501222001
501222101 PIN RETAINING SCREW 501222101
501222301 NEEDLE 501222301
501222401 SCREEN 501222401
501223001 SCREW&LOCKWASHER 501223001
501268501 IDLE MIXTURE SCREW 501268501
501269001 MIXTURE SCREW SPRING 501269001
501427101 CHOKE SHAFT 501427101
501485201 PIN RETAINING SCREW 501485201
501691101 THROTTLE FLAP 501691101
501821701 WASHER 501821701
501821801 THROTTLE SH."E"RING 501821801
502012201 CHOKE SHUTTER 502012201
503453001 THROTTLE SH.&LEVER 503453001
503486301 SCREW 503486301
503578701 IDLE SPEED SCREW 503578701
503599501 MAIN MIXTURE SCREW 503599501
503604101 SCREW 503604101
503698801 FUEL PUMP COVER 503698801
504026500 THRO.LEVER RET.SCREW 504026500
504210053 SPRING 504210053
504860406 CHOKE LEVER 504860406
504860411 THROTTLE LEVER 504860411
504860413 CHOKE SHAFT 504860413
505316605 THROTTLE SH. SPRING 505316605
